CoreStation HX3000
Uncompromised workstation power, delivered from the data center
The HX3000 extends the capabilities of the HX platform, allowing organisations to support a broader range of users within a single, unified infrastructure. While the HX2000 is optimized for standard professional applications, the HX3000 unlocks the performance for the most demanding workloads.
Both platforms share the same architecture, management model, and administrator experience, enabling IT teams to deploy the right level of compute for each user without introducing additional complexity. Users can be assigned to HX2000 or HX3000 resources based on workload requirements, ensuring performance is matched to business and end user needs.
By combining HX2000 and HX3000, businesses can optimise cost, performance, and scalability while ensuring every user has access to the compute resources their role demands.
VIEW DATASHEET
Why Choose CoreStation HX3000
Ideal for power users that cannot be virtualized, without compromise on manageability.
AI optimized compute
Intel Core CPUs with NPU technology and an optional NVIDIA GPU provide a solution ready for AI workloads.
Performance without compromise
Bare metal compute node ensures maximum performance output, nothing is shared and user data is fully protected.
Ultra-low latency
Remove resource contention and reduce latency with the client OS installed direct on the bare-metal HX3000 node, without the need for a hypervisor.
CoreStation HX3000 is designed and built for…
Power users that require the dedicated compute resources and low latency performance of a bare metal workstation, with the peace of mind provided by enterprise management
Traders
Dedicated systems with high clock speed processors to execute trades at any time, with lowest possible latency.
Developers
AI-enabled computing resources and low-latency infrastructure to develop and test complex applications and models.
Intelligence Analysts
Processing and analyzing vast amounts of data from various sources, including satellite imagery, signals intelligence and open-source information.
Command and Control
Ensure operational security by isolating mission critical data and secure air gapped network connection to each node.
CoreStation HX3000 Workstation Specifications in Detail
| Form Factor | 12 HX3000 Nodes in the 5U HX5 Enclosure |
| CPU | Intel Core Ultra Processors (Series 2) Core Ultra 9 285, 24 cores, up to 5.6GHz core frequency Core Ultra 9 285K, 24 cores, up to 5.7GHz core frequency |
| AI Ready | CPU Integrated Neural Processing Unit (NPU) |
| Memory | Up to 128GB RAM, 2x DDR5 SODIMMs Memory bandwidth of up to 6400 MT/S |
| Storage | 1 or 2 M.2 NVMe SSD, up to 4TB capacity RAID 0 & 1 config using Intel VMD RAID Controller |
| Graphics (GPU) | Intel Arc Graphics NVIDIA RTX 2000 Ada NVIDIA RTX Pro 2000 & 4000 SFF Blackwell |
| Networking | Intel E610 10GbE |
| OS Support | Microsoft Windows 11 Ubuntu Desktop |
| Node Management | Amulet Hotkey CoreStation HX out-of-band management |
| Enclosure | CoreStation HX5 Enclosure provides power, networking & management |
| Dimensions | 196mm, 35mm, 445mm (H/W/D) Depth including HX5 enclosure – 602mm |
Configure Your CoreStation Workstation
CoreStation workstations are fully customizable to meet your specific requirements. To find out more click the enquire now button
